SIPTOK / PRODUCT RANGE
SIP Servers & IP PBX Systems
SIP communication infrastructure for connected facilities.
View system connectionsProduct models
Compare up to 3 models in one family, or add models and quantities to your project.
A CONNECTED PRODUCT FAMILY
IP PBX Systems in the system.
See how ip pbx systems fit with the operator equipment and interfaces in an example installation. The photographs and model links refer to the supplied SipTok catalogue.
SIPTOK · SCHEMATIC DIAGRAM
IP PBX Systems: a typical system connection
Ethernet / LANSelect a product photograph for model details
Scroll across the diagram to explore each connection.
01 · Control room & system control
Example ip pbx systemST-PBX-100UIP PBX 100 EndpointsEthernet / LANView product
02 · Site network
Example Ethernet switchST-PoE-8P8 Port PoE SwitchLAN switch · independent power reviewView product
01
Paging workflow
The operator selects the intended area and the configured platform coordinates the supported announcement workflow.
02
Call workflow
Compatible SIP endpoints establish calls through the configured platform. Define extensions, permissions and call destinations during commissioning.
Connection, power & commissioning notes
- Ethernet branches connect the shown IP devices to the site LAN switch. This is a connection concept, not a cable-routing or electrical wiring drawing.
- SIP handles call setup. RTP audio follows the configured media path; it does not necessarily pass through the SIP server. Multicast is a separate, model-supported paging option.
- Confirm power for each device independently. A PoE switch in this example does not establish the required PoE class, port budget or a universal one-cable installation.
- Models illustrate alternative or separately zoned endpoints. This is not a fixed bill of materials; select quantities and installation details for the project.
Photographs show actual SipTok models. This is a conceptual connection diagram; cable routes, power and final equipment are confirmed during system design.
SELECT WITH CONFIDENCE
Choosing ip pbx systems.
A SIP server for an IP PA system coordinates compatible endpoints and the configured calling or paging services. SipTok IP PBX models include embedded software and published capacity data. Size a SIP server against both the endpoint estate and expected concurrent activity, then confirm the intended paging functions.
- Define registered extensions and simultaneous sessions as separate requirements.
- Confirm paging, calling and operator workflows with the selected configuration.
- Plan network services, power continuity and access controls as part of deployment.
How do I choose the right product?
Start with the application, installation environment and required communication method. Review the specific model’s datasheet, then share your site requirements with SipTok.
Do all models support SIP and PoE?
No. SIP endpoints, CCTV active speakers, alarm panels and switches have different interfaces and power requirements. Check the actual model specifications.
Can I request a project quotation?
Yes. Include models, quantities, site details and the intended application so our team can discuss the right configuration.
